Claas Axos 340 CX
| 2008 - ???? |
Axos Series | Utility tractor |
|
Production |
Manufacturer: | Claas
|
Type: | Utility tractor
|
Factory: | Le Mans, France
|
Claas Axos 340 CX Power |
Engine: | 102 hp 76.1 kW
|
Mechanical |
Chassis: | 4x4 MFWD 4WD
|
Cab: | High-profile cab standard (low-profile optional) with heat and opening rear window. Optional air-conditioning, radio, opening front window, and sunroof. ROPS optional.
|
Transmissions: | 20-speed partial power shift with power shuttle
|
| 30-speed
|
Transmission details ... |
Hydraulics |
Valves: | up to 3
|
Total flow: | 15.9 gpm 60.2 lpm
|
Tractor hitch |
Rear Type: | II
|
| III/II (optional)
|
Rear lift (at 24"/610mm): | 8,378 lbs 3800 kg
|
Front Hitch: | optional
|
Front lift: | 6,173 lbs 2800 kg
|
Power Take-off (PTO) |
Rear RPM: | 540/1000
|
| 540/540E (optional)
|
| 540/540E/1000 (optional)
|
Front PTO: | optional
|
Front RPM: | 1000
|
