Cameco 345-B
|
|
| Production | |
| Manufacturer | Cameco |
| Four-wheel Drive (4WD) tractor | |
| Built in Thibodaux, Louisiana, USA | |
| Cameco 345-B Engines | |
| Caterpillar 10.5L 6-cyl diesel | |
| John Deere 6-cyl diesel | |
 Engine details ... |
| Cameco 345-B Transmissions | |
| 11-speed power shift | |
| 10-speed | |
 Transmission details ... |
| Cameco 345-B Power | |
| Engine | 250 hp 186.4 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Hydraulic wet discs brakes | |
| Trailer brakes | air brakes (optional) |
| Open operator station. Cab available with air-conditioning. | |
| Photos | |
| No photos of the Cameco 345-B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 100 gal 378.5 L |
| Hydraulic system | 57 gal 215.7 L |
| Hydraulics | |
| Type | open center |
| Capacity | 57 gal 215.7 L |
| Pressure | 2000 psi 137.9 bar |
| Valves | 2 to 5 |
| Pump flow | 25 gpm 94.6 lpm |
| Tractor hitch | |
| Rear Type | III OptOptional |
| Dimensions & Tires | |
| Weight | 23,400 lbs 10614 kg |
| Front tire | 23.1x30 |
| Rear tire | 23.1x30 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 130 |
| 140 | |
| Batteries | 2 |
| Battery CCA | 925 |
| Battery volts | 12 |
| References | |
 | |
| 345-B published by Cameco |
