Massey Ferguson 7499
| | 2009 - 2012 |
| 7400 Series | | Row-Crop tractor |
|
Series map:
7497
7499
205.0hp
220.0hp
| Production |
| Manufacturer | Massey Ferguson
|
| Row-Crop tractor |
| Built in Beauvais, France |
| Massey Ferguson 7499 Power |
| Engine | 220 hp
164.1 kW
|
| PTO (claimed) | 180 hp
134.2 kW
|
| Drawbar (tested) | 162.36 hp
121.1 kW
|
| PTO (tested) | 217.30 hp
162.0 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic front and rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. Pneumatic cab suspension optional. |
| Capacity |
| Fuel | 94 gal
355.8 L
|
| Hydraulic system | 15.3 gal
57.9 L
|
| Hydraulics |
| Type | closed center
|
| Capacity | 15.3 gal
57.9 L
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 3 or 4
|
| Total flow | 29.1 gpm
110.1 lpm
|
| | 39.6 gpm (optional)
149.9 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Control | lower-link draft sensing
|
| Rear lift (at 24"/610mm) | 16140 lbs
7321 kg
|
| Front Hitch | optional
|
| Front lift | 8800 lbs
3991 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540/540E/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 175
|
| Batteries | 2
|
| Battery CCA | 600
|
| Battery volts | 12
|
| References |
 |
| 6400/7400 Series published in 2010, by Massey Ferguson |
