New Holland TN60DA

New Holland TN60DA tractor photo
2004 - 2008
TN-A Series
Utility tractor
Manufacturer:New Holland
Type:Utility tractor
Factory:Jesi, Italy
New Holland TN60DA Power
Engine (gross):57 hp
42.5 kW
Engine:55 hp
41.0 kW
PTO (claimed):45 hp
33.6 kW
Drawbar (tested):38.3 hp
28.6 kW
PTO (tested):48.3 hp
36.0 kW
power test details ...
New Holland TN60DA Engine
Iveco 2.9L 3-cyl diesel
Fuel tank:23 gal
87.1 L
Engine details ...
Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Steering:hydrostatic power
Brakes:differential wet disc
Cab:Cab standard.
Transmissions:16-speed partially synchronized with mechanical shuttle
 16-speed partially synchronized with power shuttle
Transmission details ...
No photos of the New Holland TN60DA are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Type:open center
Pressure:2755 psi
190.0 bar
Valves:1 to 4
Pump flow:12.8 gpm
48.4 lpm
 16.9 gpm
64.0 lpm (optional)
Steering flow:7.4 gpm
28.0 lpm
 9.4 gpm
35.6 lpm (with power shuttle)
Tractor hitch
Rear Type:II/I
Rear lift (at 24"/610mm):3,960 lbs
1796 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
Wheelbase:83.9 inches
213 cm (2WD)
 81.3 inches
206 cm (4WD)
Weight:5588 to 6450 pounds
Full dimensions and tires ...
Charging system:alternator
Charging amps:85
Battery CCA:730
Battery volts:12
