Tractors > CaseIH > Farmall 75A

CaseIH Farmall 75A



CaseIH Farmall 75A tractor photo
2010 - 2015
Farmall A Series
Utility tractor
Series:Farmall 65A ← Farmall 75A
Production
Manufacturer:CaseIH
Type:Utility tractor
Factory:India
CaseIH Farmall 75A Power
Engine (gross):75 hp
55.9 kW
PTO (claimed):66 hp
49.2 kW
PTO (tested):68.18 hp
50.8 kW
power test details ...
CaseIH Farmall 75A Engine
FPT 3.2L 4-cyl diesel
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:mechanical rear differential lock with foot pedal, limited slip 4WD front axle
Steering:hydrostatic power
Brakes:differential mechanical dry disc
Cab:Two-post foldable ROPS.
Transmission:8-speed partially synchronized
Transmission details ...
Photos
No photos of the CaseIH Farmall 75A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:16.4 gal
62.1 L
Steering:8.5 qts
8.0 L
Hydraulics
Type:open center fixed displacement gear pump
Valves:1 or 2
Pump flow:10.4 gpm
39.4 lpm
Total flow:18.7 gpm
70.8 lpm
Steering cap.:8.5 qts
8.0 L
Tractor hitch
Rear Type:2/1
Control:position control and mechanical draft sensing
Rear lift (at 24"/610mm):2,954 lbs
1339 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
Weight:5059 to 5688 pounds
Front tire:7.50x16
2WD Rear tire:16.9x30
Full dimensions and tires ...
CaseIH Farmall 75A attachments
front-end loader
Attachment details ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:65
Charging volts:12
Battery CCA:800
Battery volts:12
