Bobcat CT335
|
|
| Production | |
| Distributor | Bobcat |
| Manufacturer | Daedong |
| Compact Utility tractor | |
| Built in Daegu, South Korea | |
| Variants | |
| CT335SST | shuttle shift |
| Bobcat CT335 Engine | |
| Daedong 1.8L 3-cyl diesel | |
| Fuel tank | 11.9 gal 45.0 L |
 Engine details ... | |
| Bobcat CT335 Transmissions | |
| hydrostatic | |
| 12-speed shuttle | |
 Transmission details ... |
| Bobcat CT335 Power | |
| Engine | 38 hp 28.3 kW |
| PTO (claimed) | 26.5 hp 19.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Differential wet disc brakes | |
| ROPS. Cab optional with heat and air-conditioning. | |
| Photos | |
| No photos of the Bobcat CT335 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 1 or 2 |
| Pump flow | 7.9 gpm 29.9 lpm |
| Total flow | 14.5 gpm 54.9 lpm |
| Steering flow | 6.6 gpm 25.0 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at 24"/610mm) | 1,700 lbs 771 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Mid PTO | optional |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 69.3 inches 176 cm |
| Weight | 3668 to 4081 pounds |
| Front tire | 7x16 |
| Rear tire | 12.4x24 |
 Full dimensions and tires ... | |
| Bobcat CT335 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| References | |
 | |
| Compact Tractors published in 2010, by Bobcat |
