Tractors > CaseIH > Farmall 105U

CaseIH Farmall 105U Tests



CaseIH Farmall 105U tractor photo
2008 - 2016
Model year
Farmall U Series
Utility tractor
Series map:
Farmall 95U
Farmall 105U
95.0hp
105.0hp
OCED Tractor Test 2526
Farmall 105U fuel use from test 737
OCED Tractor Test 2526
Diesel 12-speed 4WD
December 2008 - February 2009,
Link: OCED Tractor Test 2526 file
PTO performance
Max power94.4 hp
70.4 kW
Fuel use5.8 gal/hour
22.0 l/hour
Power at rated engine speed93.2 hp
69.5 kW
Fuel use5.9 gal/hour
22.3 l/hour
Power at rated PTO speed93.7 hp
69.9 kW
Fuel use5.9 gal/hour
22.3 l/hour
