Iseki TA417
|
|
| Production | |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Variants | |
| 1160 | similar Massey Ferguson model |
| Iseki TA417 Engine | |
| Isuzu 2.2L 4-cyl diesel | |
| Fuel tank | 12.7 gal 48.1 L |
 Engine details ... | |
| Iseki TA417 Power | |
| Engine | 40.4 hp 30.1 kW |
| PTO (claimed) | 39 hp 29.1 kW |
| Mechanical | |
| Four-wheel drive | |
| Four-post ROPS. Cab optional. |
| Photos | |
| No photos of the Iseki TA417 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 565@2500 |
| 677@2500 | |
| 1016@2500 | |
| 1270@2500 | |
| Dimensions & Tires | |
| Wheelbase | 74.8 inches 189 cm |
| Weight | 3814 lbs 1730 kg |
| Front tire | 8-18 |
| Rear tire | 13.6-28 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Land Leader 7 Series published in 1991, by Iseki |
