Iseki TL2501


Iseki TL2501 tractor photo
1980 - 1985
TL-01 Series
Compact Utility tractor
Series map:
TL2301
TL2501
TL2701
16.9kw
18.4kw
19.8kw
Production
ManufacturerIseki
Compact Utility tractor
Variants
TL2501F4WD
Iseki TL2501 Engine
Isuzu 1.5L 3-cyl diesel
Fuel tank7.1 gal
26.9 L
Engine details ...
Iseki TL2501 Power
Engine24.7 hp
18.4 kW
Mechanical
Two- or four-wheel drive
Open operator station.
Photos
No photos of the Iseki TL2501 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeJIS1
Power Take-off (PTO)
Rear RPM540 (1.375)
Engine RPM553@2600
731@2600
906@2600
1280@2600
Dimensions & Tires
Wheelbase65 inches
165 cm
Weight2249 to 2469 pounds
Front tire5.00-15
2WD Rear tire12.4-24
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
TL2501 references literature
TL1901/2101/2301/2501/2701 published in 1984, by Iseki
TL2501 - TL2701 (1536-912-001-0A)
