Iseki TL2101


Iseki TL2101 tractor photo
1980 - 1985
TL-01 Series
Compact Utility tractor
Series map:
TL1901
TL2101
TL2301
13.9kw
15.4kw
16.9kw
Production
ManufacturerIseki
Compact Utility tractor
Variants
TL2101F4WD
Iseki TL2101 Engine
Isuzu 1.4L 3-cyl diesel
Fuel tank7.4 gal
28.0 L
Engine details ...
Iseki TL2101 Power
Engine20.7 hp
15.4 kW
Mechanical
Two- or four-wheel drive
Open operator station.
Photos
No photos of the Iseki TL2101 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeJIS1
Power Take-off (PTO)
Rear RPM540 (1.375)
Engine RPM553@2600
731@2600
906@2600
1280@2600
Dimensions & Tires
Wheelbase62.2 inches
157 cm
Weight2094 to 2326 pounds
Front tire4.00-15
2WD Rear tire9.5-24
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
TL2101 references literature
Gold Series published in 1984, by Iseki
TL1901 - TL2301 (1444-912-001-1C)
TL1901/2101/2301/2501/2701 published in 1984, by Iseki
