Iseki TS2205
|
|
| Production | |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Iseki TS2205 Engine | |
| Isuzu 1.2L 2-cyl diesel | |
| Fuel tank | 4.2 gal 15.9 L |
 Engine details ... | |
| Iseki TS2205 Power | |
| Engine | 21.7 hp 16.2 kW |
| Mechanical | |
| Two-wheel drive | |
| Open operator station. |
| Photos | |
 | |
 Iseki TS2205 photos... | |
| Tractor hitch | |
| Rear Type | JIS0 |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 537@2300 |
| 711@2300 | |
| 890@2300 | |
| 1274@2300 | |
| Dimensions & Tires | |
| Wheelbase | 55.7 inches 141 cm |
| Weight | 1731 lbs 785 kg |
| Front tire | 5.00-12 |
| Rear tire | 9.5/9-22 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| TS1610-TS1910-TD2202-TD2205 | |
| TS2205 published in 1981, by Iseki |
