Iseki TJ75
| | 2003 - 2009 |
| TJ Series | | Utility tractor |
|
| Production |
| Manufacturer: | Iseki
|
| Type: | Utility tractor
|
| Variants |
| TJ75: | wheel tractor
|
| TJ75C: | half-track
|
| Iseki TJ75 Power |
| Engine: | 74 hp
55.2 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | wet discs
|
| Cab: | Cab with air-conditioning.
|
| Transmissions: | 24-speed 8-speed power shift
|
| | 12-speed 4-speed power shift
|
 Transmission details ... |
| Photos |
| No photos of the Iseki TJ75 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Total flow: | 7.7 gpm
29.1 lpm
|
| Tractor hitch |
| Rear Type: | JIS1
|
| | JIS2
|
| Rear lift (at ends): | 5732 lbs
2600 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 566@2600
733@2600
1061@2600
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
| Battery AH: | 72
|
