CaseIH MXU115 Tests
|
|
| OCED Tractor Test 2228 | |||
| |||
| OCED Tractor Test 2228 | |
| Diesel 24-speed 4WD September 2004 - November 2004, Link: OCED Tractor Test 2228 file | |
| PTO performance | |
| Max power: | 104.7 hp 78.1 kW |
| Fuel use: | 6.4 gal/hour 24.2 l/hour |
| Power at rated engine speed: | 101.0 hp 75.3 kW |
| Fuel use: | 6.7 gal/hour 25.4 l/hour |
| Power at rated PTO speed: | 103.7 hp 77.3 kW |
| Fuel use: | 6.7 gal/hour 25.4 l/hour |
| Drawbar performance | |
| Max power: | 93.4 hp 69.6 kW |
| Fuel use: | 7.5 gal/hour 28.4 l/hour |
| Gear 12 used for power test. | |
| Max pull: | 12,365 lbs 5608 kg |
| Gear 1-I-Low used for pull test. | |
