John Deere 8320R Tests


John Deere 8320R tractor photo
2009 - 2010
8R Series
Row-Crop tractor
8430
Series:8295R8320R8345R
8335R
OCED Tractor Test 1963
8320R fuel use from test 660
OCED Tractor Test 1963
Diesel 16-speed 4WD
October 13 - 28, 2009
Link: OCED Tractor Test 1963 file
PTO performance
Max power:307.31 hp
229.2 kW
Fuel use:16.2 gal/hour
61.3 l/hour
Power at rated engine speed:274.37 hp
204.6 kW
Fuel use:14.5 gal/hour
54.9 l/hour
Power at rated PTO speed:298.64 hp
222.7 kW
Fuel use:15.8 gal/hour
59.8 l/hour
Drawbar performance
Max power:242.32 hp
180.7 kW
Fuel use:14.7 gal/hour
55.6 l/hour
Gear 9 used for power test.
Max pull:23,682 lbs
10742 kg
Gear 5 used for pull test.
