Tractors > John Deere > 7405

John Deere 7405

1998 - 2002

Advantage Series

Utility tractor

Series map:

6605

7405

105.6hp*

116.7hp*

*Estimated engine power for comparison only.

Production
Manufacturer	John Deere
Utility tractor
Built in Monterrey, Mexico
Original price was $43,600 in 1999
The John Deere 7405 was one of the Advantage Series models designed to provide an economical alternative to the TEN series. The 7405 had the same power as the 7410 but without a cab, single transmission option, and different hydraulics.

John Deere 7405 Engine
John Deere 6.8L 6-cyl diesel
Engine details ...

John Deere 7405 Transmission
16-speed partial power shift
Transmission details ...

John Deere 7405 Power
PTO (claimed)	105 hp 78.3 kW

Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post folding ROPS.

Photos
No photos of the John Deere 7405 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.

Capacity
Fuel	54.7 gal 207.0 L
Hydraulic system	15 gal 56.8 L
4WD Hydraulic system	17 gal 64.3 L
	18 gal (4WD creeper) 68.1 L
Front axle	6.8 qts 6.4 L
Front hubs	0.8 qts 0.8 L

Hydraulics
Type	constant-flow load-sensing
Capacity	15 gal 56.8 L
4WD Capacity	17 gal 64.3 L
	18 gal (4WD creeper) 68.1 L
Pressure	2750 psi 189.6 bar
Valves	2
Total flow	17.5 gpm 66.2 lpm

Tractor hitch
Rear Type	II
Control	position and electro-hydraulic lower-link draft control
Rear lift	7970 lbs 3615 kg

Power Take-off (PTO)
Rear PTO	independent
Rear PTO Type	540/1000 (1.375)

Dimensions & Tires
2WD Wheelbase	106.3 inches 270 cm
4WD Wheelbase	104.3 inches 264 cm
Weight	10750 to 11575 pounds
Front tire	10.00-16
Rear tire	18.4-38 (2WD)
Full dimensions and tires ...

7405 Serial Numbers
Location:	Serial number plate on the right side of the tractor frame, above the front axle.
1998	1001
1999	1719
2000	1842
2001	2050
2002	2104
FAQ: How to read a serial number table.

Electrical
Ground	negative
Charging system	alternator
Charging amps	65
Battery CCA	950
Battery volts	12
Battery AH	110

References

6000 Series Tractors and Advantage Series Tractors Product Information Handbook published in 1997, by John Deere
6000 TEN Series and Advantage Series Tractors published in 1998, by John Deere
6000 TEN Series Tractors and Advantage Series Tractors Product Information Handbook published in 1998, by John Deere
New 85- to 105-HP Advantage Series Tractors published in 1997, by John Deere
Advantage Series Tractors published in 1999, by John Deere
6005 and 7005 Series published in 2001, by John Deere
7000 TEN Series Tractors and 7405 Advantage Series Tractors Product Information Handbook published in 1998, by John Deere
7000 TEN Series Tractors and 7405 Advantage Series Tractors Product Information Handbook published in 1999, by John Deere
