New Holland T6030 Elite Tests
|
|
| Tractor Tests | |
| OECD 2484: diesel AutoShift 4WD | |
| OECD 2493: diesel Range Command 4WD |
| OCED Tractor Test 2484 | |||
| |||
| OCED Tractor Test 2484 | |
| Diesel AutoShift 4WD March 2008 - June 2008, Link: OCED Tractor Test 2484 file | |
| PTO performance | |
| Max power | 110.4 hp 82.3 kW |
| Fuel use | 6.4 gal/hour 24.2 l/hour |
| Power at rated engine speed | 98.6 hp 73.5 kW |
| Fuel use | 6.5 gal/hour 24.6 l/hour |
| Power at rated PTO speed | 106.6 hp 79.5 kW |
| Fuel use | 6.8 gal/hour 25.7 l/hour |
| Drawbar performance | |
| Max power | 79.1 hp 59.0 kW |
| Fuel use | 6.5 gal/hour 24.6 l/hour |
| Gear 8L used for power test. | |
| Max pull | 11,985 lbs 5436 kg |
| Gear 1L used for pull test. | |
| OCED Tractor Test 2493 | |||
| |||
| OCED Tractor Test 2493 | |
| Diesel Range Command 4WD September 2008 - December 2008, Link: OCED Tractor Test 2493 file | |
| PTO performance | |
| Max power | 114.3 hp 85.2 kW |
| Fuel use | 6.6 gal/hour 25.0 l/hour |
| Power at rated engine speed | 102.2 hp 76.2 kW |
| Fuel use | 6.4 gal/hour 24.2 l/hour |
| Power at rated PTO speed | 109.4 hp 81.6 kW |
| Fuel use | 6.5 gal/hour 24.6 l/hour |
| Drawbar performance | |
| Max power | 74.3 hp 55.4 kW |
| Fuel use | 6.2 gal/hour 23.5 l/hour |
| Gear 2M used for power test. | |
| Max pull | 12,160 lbs 5515 kg |
| Gear 1L used for pull test. | |
