John Deere 20A
|
|
| Production | |
| Distributor | John Deere |
| Manufacturer | Goldoni |
| Orchard/Vineyard tractor | |
| Built in Italy | |
| John Deere 20A Engine | |
| Lombardini 1.0L 2-cyl diesel | |
 Engine details ... |
| John Deere 20A Transmission | |
| 6-speed gear | |
 Transmission details ... |
| John Deere 20A Power | |
| Engine | 21 hp 15.7 kW |
| PTO (claimed) | 17 hp 12.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| Two-post ROPS. | |
| Photos | |
| No photos of the John Deere 20A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 6 gal 22.7 L |
| Hydraulic system | 1.7 gal 6.4 L |
| Hydraulics | |
| Type | open center |
| Capacity | 1.7 gal 6.4 L |
| Pressure | 1813 psi 125.0 bar |
| Total flow | 9 gpm 34.1 lpm |
| Steering press. | 1305 psi 90.0 bar |
| Tractor hitch | |
| Rear Type | 1/1N |
| Rear lift | 1,100 lbs 498 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Wheelbase | 39.3 inches 99 cm |
| Weight | 1,654 lbs 750 kg |
| Front tire | 6.5/80x15 |
| Rear tire | 6.5/80x15 |
 Full dimensions and tires ... | |
| 20A Serial Numbers | |
| Location: | On the left-front, just ahead of the front tire, behind the muffler. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 14 |
| Battery volts | 12 |
| Battery AH | 45 |
| References | |
 | |
| Milenio 20A, 40A Y 40R published in 2003, by John Deere | |
| Serie Milenio published in 2010, by John Deere | |
| Specialty Tractors published in 2008, by John Deere |
