Tractors > New Holland > TG245

New Holland TG245

New Holland TG245 tractor photo
2006 - 2007   TG II Series
Row-Crop tractor
Previous model:New Holland TG230
Next model:New Holland T8020
Series next:New Holland TG275
Series back:New Holland TG215



Manufacturer:New Holland
Factory:Racine, Wisconsin, USA

New Holland TG245 Engine:

   CNH 8.3L 6-cyl diesel
full engine details ...


Fuel:180 gal [681.3 L]

3-Point Hitch:

Rear Type:III
Rear lift:14,070 lbs [6382 kg]
 16,375 lbs [7427 kg] (optional)

Power Take-off (PTO):

Rear PTO:independent
Rear RPM:1000 (1.75)
 540/1000 (1.375)

Dimensions & Tires:

Wheelbase:121.2 inches [307 cm]
 129.3 inches [328 cm] (SuperSteer)
Weight:21,270 lbs [9648 kg]
full dimensions and tires ...

New Holland TG245 attachments:

 front-end loader
all TG245 attachments ...

TG245 Serial Numbers:

how to read serial numbers...


New Holland TG245 Power:

Engine:248 hp [184.9 kW]
PTO (claimed):200 hp [149.1 kW]
Drawbar (tested):178.08 hp [132.8 kW]
PTO (tested):245.61 hp [183.2 kW]
power test details ...


Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:hydraulic wet disc
Cab:Cab standard with air-conditioning.
