Versatile 846
|
|
| Production | |
| Manufacturer | Versatile |
| Four-wheel Drive (4WD) tractor | |
| Built in Winnipeg, Manitoba, Canada | |
| The 846 appeared in Versatile black, red, and gold until 1989; afterwards it was produced in Ford blue. | |
| Versatile 846 Engine | |
| Cummins 10.0L 6-cyl diesel | |
 Engine details ... |
| Versatile 846 Transmissions | |
| 12-speed constant mesh | |
| 15-speed partially synchronized | |
 Transmission details ... |
| Versatile 846 Power | |
| Engine | 230 hp 171.5 kW |
| PTO (claimed) | 202 hp 150.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | outboard planetary |
| inboard planetary (row-crop) | |
| Articulated power steering | |
| Hydraulic disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
 | |
 Versatile 846 photos... | |
| Capacity | |
| Fuel | 246 gal 931.1 L |
| Hydraulic system | 15.3 gal 57.9 L |
| Hydraulics | |
| Type | closed center load sensing *Steering pump is open center. |
| Capacity | 15.3 gal 57.9 L |
| Pressure | 2250 psi 155.1 bar |
| Valves | 4 to 5 |
| Pump flow | 25.2 gpm 95.4 lpm |
| Steering flow | 25.9 gpm 98.0 lpm |
| Steering press. | 2300 psi 158.6 bar |
| Tractor hitch | |
| Rear Type | III |
| III/IVN | |
| Control | position control |
| Rear lift (at 24"/610mm) | 10313 lbs (III) 4677 kg |
| 13036 lbs (IV/III) 5913 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 (1.75) |
| Dimensions & Tires | |
| Wheelbase | 130 inches 330 cm |
| Weight | 18000 to 23000 pounds |
 Full dimensions and tires ... | |
| 846 Serial Numbers | |
| Location: | Serial number plate on the cab door post. |
| 1988 | 846 88 330335 |
| 1989 | 846 89 D430159 |
| 1990 | 846 90 D450298 |
| 1991 | 846 91 D475001 |
| 1992 | 846 92 D485051 |
| 1993 | 846 93 D930035 |
| Final | 846 93 D931211 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 90 |
| Batteries | 4 |
| Battery CCA | 625 |
| Battery volts | 12 |
| References | |
 | |
| 846 and 876 - Designation 6 Tractors published in 1987, by Versatile |
