Tractors > John Deere > 7230

John Deere 7230



John Deere 7230 tractor photo
2007 - 2011
7030 Small-Frame Series
Row-Crop tractor
Series map:
7130
7230
7330
121.0hp
135.0hp
150.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $69,616 in 2011
The basic 7230 was available with ROPS or a basic cab. Upgraded hydraulics and hitch were optional with ROPS. Upgraded systems with a cab were only available on the 7230 Premium model.
Variants
7230base tractor
7230 Premiumdeluxe tractor
John Deere 7230 Engine
John Deere 6.8L 6-cyl diesel
Engine details ...
John Deere 7230 Transmissions
12-speed full synchro shift
16-speed full synchro shift
16-speed partial power shift
24-speed partial power shift
Transmission details ...
John Deere 7230 Power
Engine (gross)135 hp
100.7 kW
Engine135 hp
100.7 kW
PTO (claimed)110 hp
82.0 kW
Mechanical
Two- or four-wheel drive
Power steering
Differential hydraulic wet disc brakes
Two-post Roll-Gard ROPS. Cab optional.
Photos
John Deere 7230
John Deere 7230 photos...
Capacity
Fuel54.7 gal
207.0 L
 66 galOptOptional
249.8 L
Hydraulic system13.7 gal
51.9 L
Front axle8.8 qts
8.3 L
Front hubs1.6 qts
1.5 L
Hydraulics
Typeconstant flow load sensing
 closed-center load sensing (optional ROPS)
Capacity13.7 gal
51.9 L
Pressure2900 psi
200.0 bar
Valves2 to 4
Pump flow21.1 gpm
79.9 lpm
 29 gpmOptOptional
109.8 lpm
Tractor hitch
Rear TypeII
Controlposition control
 electronic lower-link (optional ROPS)
Rear lift (at 24"/610mm)5,915 lbs
2683 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
 540/540E/1000 OptOptional
Engine RPM540@2124
 540@2143 (reversible)
 1000@2208
Dimensions & Tires
2WD Wheelbase106.3 inches
270 cm
4WD Wheelbase104.3 inches
264 cm
Weight9657 to 12755 pounds
Front tire10.00-16
2WD Rear tire18.4R38
Full dimensions and tires ...
7230 Serial Number Location
John Deere 7230 serial number location
Right side of main frame above front axle
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Battery volts12
References
7230 references literature
6030 and 7030 Series Tractors published in 2007, by John Deere
