Tractors > Yanmar > FX215

Yanmar FX215



Yanmar FX215 tractor photo
1987 - 1992
Compact Utility tractor
Series map:
FX195
FX215
FX235
13.9kw
15.4kw
16.9kw
Production
ManufacturerYanmar
Compact Utility tractor
Variants
F2152WD gear
F215D4WD gear
FX2152WD power shift
FX215D4WD power shift
Yanmar FX215 Engine
Yanmar 1.4L 3-cyl diesel
Fuel tank6.6 gal
25.0 L
Engine details ...
Yanmar FX215 Transmission
9-speed partial power shift
Transmission details ...
Yanmar FX215 Power
Engine20.7 hp
15.4 kW
Mechanical
Two- or four-wheel drive
Open operator station.
Photos
No photos of the Yanmar FX215 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeJIS1
Power Take-off (PTO)
Rear RPM540 (1.375)
Engine RPM574@2500
698@2500
958@2500
1293@2500
Dimensions & Tires
2WD Wheelbase59.5 inches
151 cm
4WD Wheelbase60 inches
152 cm
Weight2050 to 2238 pounds
Front tire4.00-12
2WD Rear tire9.5-22
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps16
Battery volts12
Battery AH75
References
FX215 references literature
F195/FX195/F215/FX215/F235/FX235/F255/FX255/F265/FX265 (4) published in 1987
