Kubota L4150DTN
|
|
| Production | |
| Manufacturer | Kubota |
| Orchard/Vineyard tractor | |
| Kubota L4150DTN Engine | |
| Kubota 2.3L 5-cyl diesel | |
 Engine details ... |
| Kubota L4150DTN Transmission | |
| 8-speed partially synchronized | |
 Transmission details ... |
| Kubota L4150DTN Power | |
| Engine | 50 hp 37.3 kW |
| PTO (claimed) | 40 hp 29.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Steering | power |
| Mechanical wet disc brakes | |
| Two-post ROPS with optional sunshade. | |
| Photos | |
| No photos of the Kubota L4150DTN are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 12.2 gal 46.2 L |
| Hydraulic system | 10.6 gal 40.1 L |
| Hydraulics | |
| Type | open center |
| Capacity | 10.6 gal 40.1 L |
| Pressure | 2500 psi 172.4 bar |
| Valves | 0 or 1 |
| Pump flow | 9.0 gpm 34.1 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 3525 lbs 1598 kg |
| Rear lift (at 24"/610mm) | 2650 lbs 1202 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2243 |
| 750@2391 | |
| Dimensions & Tires | |
| Wheelbase | 78.7 inches 199 cm |
| Weight | 4145 lbs 1880 kg |
| Front tire | 8-16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 35 |
| Battery volts | 12 |
| Battery AH | 110 |
| References | |
 | |
| Narrow L4150DT-N published in 1987, by Kubota |
