Massey Ferguson 365
|
|
| Production | |
| Manufacturer | Massey Ferguson |
| Utility tractor | |
| Built in Coventry, England | |
| Massey Ferguson 365 Engine | |
| Perkins 3.9L 4-cyl diesel | |
 Engine details ... |
| Massey Ferguson 365 Transmissions | |
| 8-speed synchronized | |
| 12-speed synchronized | |
| 12-speed two-speed power shift | |
 Transmission details ... |
| Massey Ferguson 365 Power | |
| Engine | 61 hp 45.5 kW |
| PTO (claimed) | 55 hp 41.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| Two- or four-post ROPS. Cab available. | |
| Capacity | |
| Fuel | 28.5 gal 107.9 L |
| Hydraulic system | 12.5 gal 47.3 L |
| Hydraulics | |
| Type | open center |
| Capacity | 12.5 gal 47.3 L |
| Pressure | 3000 psi 206.8 bar |
| Pump flow | 9.5 gpm (aux pump) 36.0 lpm |
| 7.3 gpm (hitch pump) 27.6 lpm | |
| Total flow | 16.8 gpm 63.6 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and draft control |
| Rear lift (at ends) | 4729 lbs (II/I interchangeable)*Capacity with links horizontal 2145 kg |
| 5575 lbs (II/I interchangeable with assist ram)*Capacity with links horizontal 2528 kg | |
| 5701 lbs (II fixed)*Capacity with links horizontal 2585 kg | |
| 6744 lbs (II fixed with assist ram)*Capacity with links horizontal 3059 kg | |
| 5410 lbs (II wrist-action)*Capacity with links horizontal 2453 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1893 |
| 1000@1900 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 84.1 inches 213 cm |
| 4WD Wheelbase | 92.5 inches 234 cm |
| Weight | 6861 to 7685 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 18.4/15-30 |
 Full dimensions and tires ... | |
| 365 Serial Number Location | |
 | |
| Serial number plate on the right side of the tractor, near the brake pedals. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 45 |
| Battery CCA | 420 (2x) |
| 540 (1x) | |
| Battery volts | 12 |
| References | |
 | |
| 300 published in 1986, by Massey Ferguson | |
| 300 published in 1988, by Massey Ferguson | |
| 300 Series Tractors Data Book published in 1992, by Massey Ferguson | |
| M-F 300 Series Tractor Workshop Manual (1449 244M1) published in 1991 |
