Challenger MT535B Tests
|
|
| Tractor Tests | |
| OECD 2546: diesel AutoPower VI 4WD | |
| OECD 2431: diesel CVT 4WD |
| OCED Tractor Test 2546 | |||
| |||
| OCED Tractor Test 2546 | |
| Diesel AutoPower VI 4WD July 2009 - October 2009, Link: OCED Tractor Test 2546 file | |
| PTO performance | |
| Max power | 142.9 hp 106.6 kW |
| Fuel use | 7.8 gal/hour 29.5 l/hour |
| Power at rated engine speed | 126.1 hp 94.0 kW |
| Fuel use | 7.9 gal/hour 29.9 l/hour |
| Power at rated PTO speed | 135.7 hp 101.2 kW |
| Fuel use | 7.9 gal/hour 29.9 l/hour |
| Drawbar performance | |
| Max power | 78.9 hp 58.8 kW |
| Fuel use | 6.8 gal/hour 25.7 l/hour |
| Gear 3A used for power test. | |
| Max pull | 13,015 lbs 5903 kg |
| Gear 1D used for pull test. | |
| OCED Tractor Test 2431 | |||
| |||
| OCED Tractor Test 2431 | |
| Diesel CVT 4WD March 2008 - May 2008, Link: OCED Tractor Test 2431 file | |
| PTO performance | |
| Max power | 145.9 hp 108.8 kW |
| Fuel use | 8.1 gal/hour 30.7 l/hour |
| Power at rated engine speed | 128.4 hp 95.7 kW |
| Fuel use | 8.2 gal/hour 31.0 l/hour |
| Power at rated PTO speed | 138.2 hp 103.1 kW |
| Fuel use | 8.0 gal/hour 30.3 l/hour |
| Drawbar performance | |
| Max power | 107.3 hp 80.0 kW |
| Fuel use | 8.2 gal/hour 31.0 l/hour |
| Pull at 7.9 KPH | |
| Max pull | 16,230 lbs 7361 kg |
| Pull at 3.6 KPH | |
