Challenger MT525B Tests
|
|
| Tractor Tests | |
| OECD 2433: diesel AutoPower VI 4WD | |
| OECD 2430: diesel CVT 4WD |
| OCED Tractor Test 2433 | |||
| |||
| OCED Tractor Test 2433 | |
| Diesel AutoPower VI 4WD September 2007 - November 2007, Link: OCED Tractor Test 2433 file | |
| PTO performance | |
| Max power | 122.2 hp 91.1 kW |
| Fuel use | 7.3 gal/hour 27.6 l/hour |
| Power at rated engine speed | 102.7 hp 76.6 kW |
| Fuel use | 6.9 gal/hour 26.1 l/hour |
| Power at rated PTO speed | 120.7 hp 90.0 kW |
| Fuel use | 7.3 gal/hour 27.6 l/hour |
| Drawbar performance | |
| Max power | 73.8 hp 55.0 kW |
| Fuel use | 6.2 gal/hour 23.5 l/hour |
| Gear 3A used for power test. | |
| Max pull | 10,655 lbs 4833 kg |
| Gear 1C used for pull test. | |
| OCED Tractor Test 2430 | |||
| |||
| OCED Tractor Test 2430 | |
| Diesel CVT 4WD September 2007 - November 2007, Link: OCED Tractor Test 2430 file | |
| PTO performance | |
| Max power | 121.0 hp 90.2 kW |
| Fuel use | 7.1 gal/hour 26.9 l/hour |
| Power at rated engine speed | 103.5 hp 77.2 kW |
| Fuel use | 6.8 gal/hour 25.7 l/hour |
| Power at rated PTO speed | 119.8 hp 89.3 kW |
| Fuel use | 7.1 gal/hour 26.9 l/hour |
| Drawbar performance | |
| Max power | 79.4 hp 59.2 kW |
| Fuel use | 6.7 gal/hour 25.4 l/hour |
| Pull at 8.0 KPH | |
| Max pull | 12,815 lbs 5812 kg |
| Pull at 3.8 KPH | |
