John Deere 7410 Hi-Crop
|
|
| Production | |
| Manufacturer | John Deere |
| High-Clearance tractor | |
| Built in Waterloo, Iowa, USA | |
| The John Deere 7410 was available as in Hi-Crop or High-Clearance configurations. The High-Clearance used the row-crop axles with taller wheels. The Hi-Crop was equipped with drop-axle housings. | |
| Variants | |
| 7410 | row-crop |
| 7410 Hi-Crop | high clearance |
| John Deere 7410 Hi-Crop Engine | |
| John Deere 6.8L 6-cyl diesel | |
 Engine details ... |
| John Deere 7410 Hi-Crop Transmissions | |
| 12-speed fully synchronized | |
| 16-speed partial power shift | |
 Transmission details ... |
| John Deere 7410 Hi-Crop Power | |
| Engine | 120 hp 89.5 kW |
| PTO (claimed) | 105 hp 78.3 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| ComfortGard cab standard. |
| Photos | |
| No photos of the John Deere 7410 Hi-Crop are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 50 gal 189.2 L |
| Hydraulic system | 15 gal (2WD) 56.8 L |
| 17 gal (4WD) 64.3 L | |
| 16 gal (2WD creeper) 60.6 L | |
| 18 gal (4WD creeper) 68.1 L | |
| Hydraulics | |
| Type | closed center pressure flow compensated (PFC) |
| Capacity | 15 gal (2WD) 56.8 L |
| 17 gal (4WD) 64.3 L | |
| 16 gal (2WD creeper) 60.6 L | |
| 18 gal (4WD creeper) 68.1 L | |
| Pressure | 2900 psi 200.0 bar |
| Valves | 2 to 4 |
| Pump flow | 26 gpm 98.4 lpm |
| 38 gpm (optional) 143.8 lpm | |
| Total flow | 16 gpm 60.6 lpm |
| Tractor hitch | |
| Rear Type | 2 |
| 3N/2 OptOptional | |
| Rear lift | 7,400 lbs (2WD) 3356 kg |
| 8,390 lbs (4WD) 3805 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 112.1 inches 284 cm |
| Front tire | 290/95R34 |
| 2WD Rear tire | 18.4-38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging amps | 120 |
| Battery CCA | 925 |
| Battery volts | 12 |
| Battery Group | 31 |
| References | |
 | |
| 7000 TEN Series published in 1999, by John Deere |
