J.I. Case 1594
| | 1983 - 1984 |
| 94 Series | | Utility tractor |
|
Series map:
1594
1694
97.0hp
112.0hp
| Production |
| Manufacturer | J.I. Case
|
| Utility tractor |
| Built in Meltham Mills, Huddersfield, England |
| Original price | $26,000 (1988)
|
| J.I. Case 1594 Power |
| Engine | 97 hp
72.3 kW
|
| Drawbar (claimed) | 74 hp
55.2 kW
|
| PTO (claimed) | 86 hp
64.1 kW
|
| Drawbar (tested) | 72.17 hp
53.8 kW
|
| PTO (tested) | 85.90 hp
64.1 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Steering | hydrostatic power
|
| Differential hydraulic wet disc brakes |
| ROPS or cab. |
| Photos |
| No photos of the J.I. Case 1594 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pressure | 2600 psi
179.3 bar
|
| Valves | 2
|
| Total flow | 10.5 gpm
39.7 lpm
|
| | 20.1 gpm (tandem)
76.1 lpm
|
| Steering flow | 7.7 gpm
29.1 lpm
|
| Steering press. | 1850 psi
127.6 bar
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift (at ends) | 7,440 lbs
3374 kg
|
| Rear lift (at 24"/610mm) | 6,290 lbs
2853 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45
|
| | 65 (heavy duty)
|
| Battery CCA | 420
|
| | 550 (heavy duty)
|
| Battery volts | 12
|
| Battery AH | 96
|
| | 128 (heavy duty)
|
| References |
 |
| Models 74L & 56L Farm Loaders published in 1983, by J.I. Case |
| 1594 - 1694 published in 1983, by J.I. Case |
| 94 Series published in 1983, by J.I. Case |
| 1194/1294/1394/1494/1594 Tractors published in 1983, by J.I. Case |
| The Tractor Specialist Buyers Guide published in 1984, by J.I. Case |
| Tractor & Loaders Buyers Guide published in 1985, by J.I. Case |
