McCormick-Deering Super AWD-6
|
|
| Production | |
| Manufacturer | McCormick-Deering (a part of International Harvester) |
| Standard-tread tractor | |
| Built in Melbourne, Australia | |
| Variants | |
| Super AW-6 | kerosense engine, standard front |
| Super AWD-6 | diesel engine, standard front |
| Super AM | kerosene engine, row-crop front |
| Super AMD | diesel engine, row-crop front |
| McCormick-Deering Super AWD-6 Engine | |
| International Harvester 4.3L 4-cyl diesel | |
| Fuel tank | 17.5 gal 66.2 L |
 Engine details ... | |
| McCormick-Deering Super AWD-6 Power |
| Mechanical | |
| Two-wheel drive | |
| Differential manual drum brakes | |
| Open operator station. |
| Photos | |
| No photos of the McCormick-Deering Super AWD-6 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Rear PTO | optional |
| Rear PTO Type | 537 |
| Dimensions & Tires | |
| Wheelbase | 76.5 inches 194 cm |
| Weight | 5768 to 7298 pounds |
| Front tire | 7.50-16 |
| Rear tire | 14x30 |
 Full dimensions and tires ... | |
| Super AWD-6 Serial Numbers | |
| Location: | Right side of tractor on clutch housing. |
| 1953 | 1755 to 3506 |
| 1954 | 3507 to 6431 |
| 1955 | 6432 to 6507 |
| 1956 | 6508 to 7968 |
| 1957 | 7959 to 8900 |
FAQ: How to read a serial number table. | |
| Belt Pulley | |
| Diameter | 11 inches 27 cm |
| Width | 7.5 inches 19 cm |
| RPM | 899 |
| Speed | 2588 ft/min 788.82 meters/min |
| References | |
 | |
| International Harvester Australia: Geelong Works by Sarah Tomac* | |
| International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick | |
| International Harvester Tractors & Equipment in Australia & New Zealand by Graeme Quick | |
| *Publication contains known errors. |
