John Deere 4240S
Series map:
4240
4240S
4440
100.0kw
98.4kw
121.0kw
| Production |
| Manufacturer | John Deere
|
| Built in Mannheim, Baden-Württemberg, Germany |
| John Deere 4240S Power |
| Engine | 132 hp
98.4 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Sound-Gard Cab standard. |
| Hydraulics |
| Type | closed center
|
| Pressure | 2250 psi
155.1 bar
|
| Pump flow | 25.4 gpm
96.1 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift | 12434 lbs
5640 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| 4240S Serial Number Location |
 |
| Serial number plate on the front right of the tractor frame, above the front axle. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 90
|
| Batteries | 2
|
| Battery volts | 12
|
| Battery AH | 88
|
| References |
 |
| Trattore 4240S published by John Deere |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on January 20, 2022 |
