John Deere 1350


John Deere 1350 tractor photo
1986 - 1994
Utility tractor
Series map:
1350
1550
28.0kw
32.4kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 1350 Engine
John Deere 2.9L 3-cyl diesel
Fuel tank19 gal
71.9 L
Engine details ...
John Deere 1350 Transmissions
8-speed synchromesh
16-speed
12-speed creeper
Transmission details ...
John Deere 1350 Power
Engine37.5 hp
28.0 kW
Mechanical
Two-wheel drive
Steeringmanual
Hydraulic wet disc brakes
four-post ROPS.
Photos
No photos of the John Deere 1350 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow5.8 gpm
22.0 lpm
 11.6 gpmOptOptional
43.9 lpm
Tractor hitch
Rear TypeII/I
Rear lift5283 lbs
2396 kg
Power Take-off (PTO)
Rear PTO Type540
 540/1000
Dimensions & Tires
Wheelbase86.7 inches
220 cm
Weight5360 lbs
2431 kg
Front tire6.50-16
Rear tire9.5-36
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery volts12
Battery AH88
References
1350 references literature
Traktor 1350 published in 1987, by John Deere
