County 774
| Production |
| Manufacturer | County
|
| Built in Fleet, England |
| County 774 Power |
| Engine | 82 hp
61.1 kW
|
| PTO (claimed) | 67 hp*At 2100 engine RPM
50.0 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | planetary
|
| Power steering |
| Wet disc brakes |
| Cab standard |
| Photos |
| No photos of the County 774 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure | 2500 psi
172.4 bar
|
| Total flow | 9.2 gpm
34.8 lpm
|
| | 9.7 gpm (After 1981)
36.7 lpm
|
| Steering flow | 2.8 gpm
10.6 lpm
|
| Steering press. | 1100 psi
75.8 bar
|
| Tractor hitch |
| Rear lift | 4600 lbs
2086 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet disc
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@1900
|
| Electrical |
| Charging system | alternator
|
| Charging amps | 46
|
| Battery volts | 12
|
| Battery AH | 128
|
| Page information |
 |
| Copyright 2026 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on April 11, 2026 |
