Toro 6-10
|
|
| Production | |
| Manufacturer | Toro |
| Standard-tread tractor | |
| Built in Minneapolis, Minnesota, USA | |
| Original price was $850 in 1925 | |
| The Toro model 6-10 was also sold as the Toro Tractor 10 and the Toro Tractor 12. | |
| Toro 6-10 Engine | |
| LeRoi 2.3L 4-cyl gasoline | |
| Fuel tank | 11 gal 41.6 L |
 Engine details ... | |
| Toro 6-10 Transmission | |
| 2-speed sliding gear | |
 Transmission details ... |
| Toro 6-10 Power | |
| Drawbar (claimed) | 6 hp 4.5 kW |
| Belt (claimed) | 10 hp 7.5 kW |
| Plows | 1 (14-inch) |
| Drawbar (tested) | 9.92 hp 7.4 kW |
| Belt (tested) | 13.31 hp 9.9 kW |
 Performance test details ... | |
| Mechanical | |
| Two-wheel drive | |
| Final drives | spur gear |
| Manual steering | |
| Open operator station. | |
| Photos | |
| No photos of the Toro 6-10 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Dimensions & Tires | |
| Weight | 2300 lbs 1043 kg |
| Front tire | 26x4 |
| Rear tire | 42x6 |
 Full dimensions and tires ... | |
| References | |
 | |
| The Toro Way of Motorized the Farm published in 1920, by Allis Chalmers |
