Farmall 1568


Farmall 1568 tractor photo
1974 - 1976
66 Series
Row-Crop tractor
Series map:
1568
172.0hp

Note: the Farmall model 1568 is the same as the International Harvester 1568. The following data is from the 1568 listing.
Production
ManufacturerFarmall (a part of International Harvester)
Row-Crop tractor
Built in Rock Island, Illinois, USA
Total built862
Original price was $26,980 in 1976
Farmall 1568 Engine
International 9.0L 8-cyl diesel
Fuel tank42 gal
159.0 L
Engine details ...
Farmall 1568 Power
Engine (gross)172 hp
128.3 kW
PTO (claimed)150 hp
111.9 kW
Drawbar (tested)130.17 hp
97.1 kW
PTO (tested)150.70 hp
112.4 kW
Performance test details ...
Mechanical
Two-wheel drive
Final drivesplanetary
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Hydraulics
Typeopen center
Rear valves1 or 2
Front valves2 OptOptional
Pump flow12 gpm
45.4 lpm
Total flow21 gpm
79.5 lpm
Tractor hitch
Rear TypeIII/II
Controldraft control
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.375)
Engine RPM1000@2300
Dimensions & Tires
Wheelbase105 inches
266 cm
Weight12,960 lbs
5878 kg
Front tire11L-15
Rear tire20.8-38
Full dimensions and tires ...
1568 Serial Numbers
19747201
19757821

FAQ: How to read a serial number table.
Links
IH V-8 Tractor Engines: article on the V8s from TractorShop.com
Electrical
Charging systemalternator
Battery volts6
References
1568 references literature
Farm Equipment Reference Catalog published in 1973, by International Harvester
