Farmall 544 Tests
|
|
| Tractor Tests | |
| NTTL 983: diesel Torque Amplifier 2WD | |
| NTTL 984: gasoline Torque Amplifier 2WD | |
| NTTL 1007: gasoline hydrostatic 2WD | |
| NTTL 1029: diesel hydrostatic 2WD |
| Nebraska Tractor Test 983 | |||
| |||
| Nebraska Tractor Test 983 | |
| Diesel Torque Amplifier 2WD September 7 - 20, 1968 Link: Nebraska Tractor Test 983 file | |
| PTO performance | |
| Power at rated engine speed | 52.95 hp 39.5 kW |
| Fuel use | 3.3 gal/hour 12.5 l/hour |
| Power at rated PTO speed | 49.66 hp 37.0 kW |
| Fuel use | 3.0 gal/hour 11.4 l/hour |
| Drawbar performance | |
| Max power | 44.56 hp 33.2 kW |
| Fuel use | 3.3 gal/hour 12.5 l/hour |
| Gear 3-Direct used for power test. | |
| Max pull | 6,528 lbs 2961 kg |
| Gear 2-TA used for pull test. | |
| Nebraska Tractor Test 984 | |||
| |||
| Nebraska Tractor Test 984 | |
| Gasoline Torque Amplifier 2WD September 7 - 20, 1968 Link: Nebraska Tractor Test 984 file | |
| PTO performance | |
| Power at rated engine speed | 52.84 hp 39.4 kW |
| Fuel use | 4.4 gal/hour 16.7 l/hour |
| Power at rated PTO speed | 50.29 hp 37.5 kW |
| Fuel use | 4.1 gal/hour 15.5 l/hour |
| Drawbar performance | |
| Max power | 44.74 hp 33.4 kW |
| Fuel use | 4.4 gal/hour 16.7 l/hour |
| Gear 3-Direct used for power test. | |
| Max pull | 6,521 lbs 2957 kg |
| Gear 2-TA used for pull test. | |
| Nebraska Tractor Test 1007 | |||
| |||
| Nebraska Tractor Test 1007 | |
| Gasoline hydrostatic 2WD April 23 - May 5, 1969 Link: Nebraska Tractor Test 1007 file | |
| PTO performance | |
| Power at rated engine speed | 53.87 hp 40.2 kW |
| Fuel use | 5.5 gal/hour 20.8 l/hour |
| Power at rated PTO speed | 49.11 hp 36.6 kW |
| Fuel use | 4.8 gal/hour 18.2 l/hour |
| Drawbar performance | |
| Max power | 40.33 hp 30.1 kW |
| Fuel use | 5.5 gal/hour 20.8 l/hour |
| Max pull | 6,518 lbs 2956 kg |
| Nebraska Tractor Test 1029 | |||
| |||
| Nebraska Tractor Test 1029 | |
| Diesel hydrostatic 2WD November 1 - 7, 1969 Link: Nebraska Tractor Test 1029 file | |
| PTO performance | |
| Power at rated engine speed | 55.52 hp 41.4 kW |
| Fuel use | 4.2 gal/hour 15.9 l/hour |
| Power at rated PTO speed | 50.06 hp 37.3 kW |
| Fuel use | 3.5 gal/hour 13.2 l/hour |
| Drawbar performance | |
| Max power | 41.58 hp 31.0 kW |
| Fuel use | 4.2 gal/hour 15.9 l/hour |
| Max pull | 6,579 lbs 2984 kg |
