International Harvester D-436

No photo available
1959 - 1962
D Series
Utility tractor
ManufacturerInternational Harvester
Utility tractor
Built in Neuss, Germany
Total built7,243
International Harvester D-436 Engine
International Harvester 2.4L 4-cyl diesel
Fuel tank7.9 gal
29.9 L
Engine details ...
International Harvester D-436 Power
Engine (gross)39 hp
29.1 kW
Two-wheel drive
Differential lockmechanical rear
Open operator station.
No photos of the International Harvester D-436 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeII/I
Power Take-off (PTO)
Rear RPM540 (1.375)
Dimensions & Tires
Wheelbase74 inches
187 cm
Weight3142 lbs
1425 kg
Front tire5.00-16
Rear tire10-28
Full dimensions and tires ...
D-436 references literature
D-436 Standard published by International Harvester
D-436 Standard published by International Harvester
