Renault 145-14 TX
|
|
| Production | |
| Manufacturer | Renault |
| Row-Crop tractor | |
| Renault 145-14 TX Engine | |
| MWM 6.2L 6-cyl diesel | |
| Fuel tank | 52.8 gal 199.8 L |
 Engine details ... | |
| Renault 145-14 TX Transmissions | |
| 12-speed synchronized | |
| 16-speed creeper | |
 Transmission details ... |
| Renault 145-14 TX Power | |
| Engine | 132.8 hp 99.0 kW |
| PTO (claimed) | 127.5 hp 95.1 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic dry disc brakes | |
| Cab standard with heat. |
| Photos | |
 | |
 Renault 145-14 TX photos... | |
| Hydraulics | |
| Pressure | 2611 psi 180.0 bar |
| Total flow | 11 gpm 41.6 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 11668 lbs 5292 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | cerametallic |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 644@2350 |
| 1105@2350 | |
| Dimensions & Tires | |
| Wheelbase | 107.9 inches 274 cm |
| Weight | 13360 lbs 6060 kg |
| Front tire | 16.9-28 |
| Rear tire | 18.4-38 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging amps | 70 |
| Batteries | 2 |
| Battery volts | 12 |
| Battery AH | 150 |
| References | |
 | |
| Renault Serie TX |
