Chamberlain 4480
Series map:
4280
4480
82.8kw
97.7kw
| Production |
| Manufacturer | Chamberlain (a part of John Deere)
|
| Built in Welshpool, Australia |
| Total built | 2,271
|
| Variants |
| 4480A | built 1975-1983
|
| 4480B | built 1983-1985
|
| Chamberlain 4480 Power |
| Engine (gross) | 131 hp
97.7 kW
|
| Engine (net) | 124 hp
92.5 kW
|
| PTO (claimed) | 119 hp
88.7 kW
|
| Mechanical |
| Two-wheel drive |
| Power steering |
| Sedan cab with heat and air-conditioning. |
| Hydraulics |
| Type | open center
|
| Valves | 2
|
| Pump flow | 13.8 gpm
52.2 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| References |
 |
| John Deere Tractors Worldwide by Don Macmillan |
| Technical Annual published in 1977, by Power Farming |
| Technical Annual published in 1981, by Power Farming |
| Technical Annual published in 1983, by Power Farming |
| Page information |
| Contact: Peter Easterlund |
| Updated on January 21, 2023 |
| Copyright 2023 TractorData LLC |
