Chamberlain Super 70
|
|
| Production | |
| Manufacturer | Chamberlain |
| Standard-tread tractor | |
| Built in Welshpool, Australia | |
| Total built | 1,010 |
| Chamberlain Super 70 Engine | |
| Detroit Diesel 3.5L 3-cyl diesel | |
| Fuel tank | 21.6 gal 81.8 L |
 Engine details ... | |
| Chamberlain Super 70 Transmission | |
| 9-speed sliding gear | |
 Transmission details ... |
| Chamberlain Super 70 Power | |
| Drawbar (claimed) | 52.5 hp 39.1 kW |
| Belt (claimed) | 65 hp 48.5 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | bull gear |
| Open operator station. | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 83 inches 210 cm |
| Weight | 9700 lbs 4399 kg |
| Front tire | 7.50x18 |
| Rear tire | 23.1x26 |
 Full dimensions and tires ... | |
| Super 70 Serial Numbers | |
| 4/1954 | 191 |
| 12/54 | 289 |
| 12/1955 | 414 |
| 12/1956 | 417 |
| 12/1957 | 536 |
| 12/1958 | 676 |
| 12/1959 | 684 |
| 12/1960 | 977 |
| 12/1961 | 1079 |
| 12/1962 | 1138 |
| Final | 1200 |
FAQ: How to read a serial number table. | |
| Belt Pulley | |
| Diameter | 13 inches 33 cm |
| Width | 7 inches 17 cm |
| RPM | 810 |
| Speed | 2740 ft/min 835.15 meters/min |
| References | |
 | |
| Super 70 Diesel Tractor published in 1960, by Chamberlain |
