Tractors > New Holland > TT50A

New Holland TT50A

New Holland TT50A tractor photo
2007 - 2008   TT-A Series
Compact Utility tractor
Next model:New Holland Workmaster 55
Series next:New Holland TT60A
Series back:New Holland TT45A



Manufacturer:New Holland
Factory:Dublin, Georgia, USA

New Holland TT50A Engine:

   Shibaura 2.2L 4-cyl diesel
full engine details ...


Fuel:13.4 gal [50.7 L]

3-Point Hitch:

Rear Type:II/I
Control:position control
Rear lift (at ends):2550 lbs [1156 kg]

Power Take-off (PTO):

Rear PTO:independent
Clutch:mechanical dry disc
Rear RPM:540 (1.375)
Engine RPM:540@2555

Dimensions & Tires:

Weight:3738 lbs [1695 kg]
full dimensions and tires ...

New Holland TT50A attachments:

 front-end loader
all TT50A attachments ...

TT50A Serial Numbers:

how to read serial numbers...


New Holland TT50A Power:

Engine (gross):48 hp [35.8 kW]
PTO (claimed):42 hp [31.3 kW]


Chassis:4x2 2WD
Final drives:bull gear
Differential lock:mechanical rear
Brakes:wet disc
Cab:Platform with two-post folding ROPS.


Type:open center
Pressure:2538 psi [175.0 bar]
Valves:0 to 2
Pump flow:9.8 gpm [37.1 lpm]
Total flow:17.2 gpm [65.1 lpm]
Steering flow:7.4 gpm [28.0 lpm]


Charging system:alternator
Charging amps:40


Cold-cranking amps:600
