Massey-Harris 201
|
|
| Production | |
| Manufacturer | Massey-Harris |
| Standard-tread tractor | |
| Built in Racine, Wisconsin, USA | |
| Original price was $1,750 in 1942 | |
| Variants | |
| 201 | Chrysler 4.1L gas |
| 202 | Continental 4.8L gas |
| 203 | Continental 5.4L distillate |
| 203G | Continental 5.4L gas |
| Massey-Harris 201 Engine | |
| Chrysler 4.0L 6-cyl gasoline | |
 Engine details ... |
| Massey-Harris 201 Transmission | |
| 4-speed gear | |
 Transmission details ... |
| Massey-Harris 201 Power | |
| Plows | 5 |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Drum and shoe brakes | |
| Open operator station. |
| Photos | |
 | |
 Massey-Harris 201 photos... | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Weight | 6700 lbs 3039 kg |
| Front tire | 7.50-18 |
| Rear tire | 13-28 |
 Full dimensions and tires ... | |
| 201 Serial Numbers | |
| 1940 | 91201 |
| 1941 | 91541 |
| 1942 | 91691 |
FAQ: How to read a serial number table. | |
| Belt Pulley | |
| Diameter | 13.5 inches 34 cm |
| Width | 8 inches 20 cm |
| RPM | 839 |
| Speed | 2962 ft/min 902.82 meters/min |
| References | |
 | |
| Two Powerful New Tractors... published in 1941, by Massey-Harris |
