Massey Ferguson 1431
| | 2004 - 2005 |
| 1400 Series | | Compact Utility tractor | | Iseki built |
|
Series map:
1429
1431
1433
28.4hp
33.0hp
33.0hp
| Production |
| Distributor | Massey Ferguson
|
| Manufacturer | Iseki
|
| Compact Utility tractor |
| Built in Matsuyama, Japan |
| Massey Ferguson 1431 Power |
| Engine (gross) | 33 hp
24.6 kW
|
| PTO (claimed) | 25.9 hp
19.3 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Two-post fixed ROPS. |
| Photos |
| No photos of the Massey Ferguson 1431 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pressure | 2134 psi
147.1 bar
|
| Pump flow | 7.7 gpm
29.1 lpm
|
| Total flow | 10.4 gpm
39.4 lpm
|
| Steering flow | 2.7 gpm
10.2 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position and response control, draft control optional
|
| Rear lift (at ends) | 2425 lbs
1099 kg
|
| Rear Arms | fixed link ends with turn-buckle stabilizers
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540
|
| Mid PTO | standard
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| MF 1400 Series published in 2003, by Massey Ferguson |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on July 16, 2024 |
