Challenger MT735
| | 2002 - 2004 |
| MT700 Series | | Agricultural Crawler tractor |
|
Series map:
MT735
MT745
235.0hp
255.0hp
| Production |
| Manufacturer | Challenger (a part of AGCO)
|
| Agricultural Crawler tractor |
| Built in Jackson, Minnesota, USA |
| Challenger MT735 Engine |
| Caterpillar 8.8L 6-cyl diesel |
| Fuel tank | 118 gal*With 88-inch rear axle
446.6 L
|
| | 178 gal*With 120 or 160 inch rear axle.
673.7 L
|
| | 208 gal*Optional, depending on machine configuration.
787.3 L
|
 Engine details ... |
| Challenger MT735 Power |
| Engine (gross) | 235 hp
175.2 kW
|
| Drawbar (claimed) | 178 hp
132.7 kW
|
| PTO (claimed) | 185 hp
138.0 kW
|
| Drawbar (tested) | 160.36 hp
119.6 kW
|
| PTO (tested) | 215.68 hp
160.8 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Steering | electro-hydraulic
|
| Wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Challenger MT735 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure | 2900 psi
200.0 bar
|
| Valves | 4 to 6
|
| Total flow | 43.5 gpm
164.6 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Rear lift | 16000 lbs
7257 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1.75)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 160
|
| Battery volts | 12
|
| References |
 |
| Challenger MT700 Series published in 2002, by AGCO |
| Challenger MT700 Series published in 2004, by AGCO |
