Challenger MT535B Tests
|
|
| Tractor Tests | |
| OECD 2213: diesel AutoPower IV 4WD | |
| OECD 2194: diesel CVT 4WD |
| OCED Tractor Test 2213 | |||
| |||
| OCED Tractor Test 2213 | |
| Diesel AutoPower IV 4WD May 2004 - June 2004, Link: OCED Tractor Test 2213 file | |
| PTO performance | |
| Max power | 116.3 hp 86.7 kW |
| Fuel use | 7.0 gal/hour 26.5 l/hour |
| Power at rated engine speed | 105.9 hp 79.0 kW |
| Fuel use | 7.3 gal/hour 27.6 l/hour |
| Power at rated PTO speed | 112.9 hp 84.2 kW |
| Fuel use | 7.2 gal/hour 27.3 l/hour |
| Drawbar performance | |
| Max power | 79.1 hp 59.0 kW |
| Fuel use | 6.7 gal/hour 25.4 l/hour |
| Gear 4TA used for power test. | |
| Max pull | 12,345 lbs 5599 kg |
| Gear 1TD used for pull test. | |
| OCED Tractor Test 2194 | |||
| |||
| OCED Tractor Test 2194 | |
| Diesel CVT 4WD February 2004 - March 2004, Link: OCED Tractor Test 2194 file | |
| PTO performance | |
| Max power | 118.1 hp 88.1 kW |
| Fuel use | 7.2 gal/hour 27.3 l/hour |
| Power at rated engine speed | 106.7 hp 79.6 kW |
| Fuel use | 7.4 gal/hour 28.0 l/hour |
| Power at rated PTO speed | 114.5 hp 85.4 kW |
| Fuel use | 7.6 gal/hour 28.8 l/hour |
| Drawbar performance | |
| Max power | 103.8 hp 77.4 kW |
| Fuel use | 8.8 gal/hour 33.3 l/hour |
| Pull at 7.7 KPH | |
| Max pull | 15,040 lbs 6822 kg |
| Pull at 3.6 KPH | |
