Tractors > Buhler Versatile > 2145

Buhler Versatile 2145



Buhler Versatile 2145 tractor photo
2000 - 2008
Genesis Series
Row-Crop tractor
Series map:
2145
2160
195.0hp
225.0hp
Production
ManufacturerBuhler Versatile
Row-Crop tractor
Built in Winnipeg, Manitoba, Canada
Original price was $99,000 in 2008
Variants
8670similar Ford model
Buhler Versatile 2145 Engine
New Holland 7.5L 6-cyl diesel
Engine details ...
Buhler Versatile 2145 Transmissions
16-speed full power shift
18-speed full power shift
Transmission details ...
Buhler Versatile 2145 Power
Engine195 hp
145.4 kW
PTO (claimed)145 hp
108.1 kW
Drawbar (tested)132.1 hp
98.5 kW
PTO (tested)167.6 hp
125.0 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Cab standard with air-conditioning.
Photos
2145 Series II with Buhler logo.
Buhler Versatile 2145 photos...
Capacity
Fuel110 gal
416.4 L
Hydraulic system31 gal
117.3 L
Hydraulics
Typeclosed center load-sensing
Capacity31 gal
117.3 L
Pressure2900 psi
200.0 bar
Valves3 or 4
Total flow30 gpm
113.6 lpm
 55 gpm*Optional HydraFlow.
208.2 lpm
Tractor hitch
Rear Type3
Controlelectronic draft sensing
Rear lift12500 lbs
5670 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchwet disc
Rear RPM540/1000 (1.375)
Engine RPM540@1878
1000@1903
Dimensions & Tires
Standard Steer Wheelbase118.3 inches
300 cm
Ultra Steer Wheelbase122.6 inches
311 cm
Weight16,970 lbs
7697 kg
Front tire14.9R28
Rear tire20.8R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps130
Batteries2
Battery CCA950
Battery volts12
References
2145 references literature
Genesis 2WD/FWD published in 2001, by Buhler Versatile
Genesis II 2WD/FWD published in 2007, by Buhler Versatile
Genesis Series published in 2008, by Buhler Versatile
