Challenger MT875B


Challenger MT875B tractor photo
2005 - 2008
MT800B Series
Agricultural Crawler tractor
Series map:
MT865B
MT875B
510.0hp
570.0hp
Production
ManufacturerChallenger (a part of AGCO)
Agricultural Crawler tractor
Built in Jackson, Minnesota, USA
Challenger MT875B Engine
Caterpillar 18.1L 6-cyl diesel
Fuel tank330 gal
1249.0 L
Engine details ...
Challenger MT875B Power
Engine (gross)570 hp
425.0 kW
PTO (claimed)425 hp
316.9 kW
Drawbar (tested)431.02 hp
321.4 kW
Performance test details ...
Mechanical
Drivecrawler
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Hydraulics
Typeclosed center PFC
Pressure2900 psi
200.0 bar
Rear valves4 to 6
Total flow43.5 gpm
164.6 lpm
 59 gpmOptOptional
223.3 lpm
Dimensions & Tracks
Wheelbase118 inches
299 cm
Weight42200 lbs
19141 kg
27.5-inch tracks
Full dimensions and tracks ...
Electrical
Groundnegative
Charging amps185
Batteries4
Battery CCA1000
Battery volts12
References
MT875B references literature
Challenger MT800B Series published in 2005, by AGCO
