CaseIH Puma 195


CaseIH Puma 195 tractor photo
2007 - 2010
Puma Series
Row-Crop tractor
Series:Puma 180Puma 195Puma 210
Puma 200
Production
Manufacturer:CaseIH
Type:Row-Crop tractor
Factories:Basildon, England
 St. Valentin, Austria
Original price:$136,985 (2010)
CaseIH Puma 195 Power
Engine:195 hp
145.4 kW
PTO (claimed):165 hp
123.0 kW
PTO (tested):189.4 hp
141.2 kW
power test details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Steering:hydrostatic power
Brakes:differential hydraulic wet disc
Trailer brakes:hydraulic optional
Cab:Cab standard.
Transmissions:17-speed full power shift
 18-speed full power shift
 19-speed full power shift
 continuously variable transmission (CVT)
Transmission details ...
Photos
No photos of the CaseIH Puma 195 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:116 gal
439.1 L (early)
 107 gal
405.0 L (late)
Hydraulic system:26.5 gal
100.3 L
Hydraulics
Type:pressure flow compensating (PFC)
Capacity:26.5 gal
100.3 L
Valves:3 to 5
Pump flow:31.7 gpm
120.0 lpm (powershift std.)
 39.6 gpm
149.9 lpm (CVT, ps-opt.)
 45 gpm
170.3 lpm (CVT opt.)
Total flow:48.7 gpm
184.3 lpm (powershift std.)
 56.6 gpm
214.2 lpm (CVT, ps-opt.)
 62 gpm
234.7 lpm (CVT opt.)
Steering flow:17 gpm
64.3 lpm
Tractor hitch
Rear Type:II/IIIN
Rear lift (at ends):12,787 lbs
5800 kg
 15,873 lbs
7199 kg (optional)
Rear lift (at 24"/610mm):10,900 lbs
4944 kg
 13,600 lbs
6168 kg (optional)
Front Hitch:optional
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000 (1-3/8)
 1000 (1-3/4)
 1000/1000E (with CVT)
Front PTO:optional
Front RPM:1000
Dimensions & Tires
Wheelbase:113.6 inches
288 cm
Weight:15708 to 17635 pounds
Front tire:16.9R30
Rear tire:20.8R42
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:150
Battery CCA:1300
Battery volts:12
