John Deere 2400
| | 1993 - 1998 |
| 2000 Series | | Utility tractor | | Zetor built |
|
| Production |
| Distributor: | John Deere
|
| Manufacturer: | Zetor
|
| Type: | Utility tractor
|
| Factory: | Brno, Czech Republic
|
| John Deere 2400 Power |
| Engine (net): | 78 hp
58.2 kW
|
| PTO (claimed): | 71.1 hp
53.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic disc
|
| Cab: | Open platform. Cab optional.
|
| Transmission: | 10-speed gear
|
 Transmission details ... |
| Photos |
| No photos of the John Deere 2400 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2610 psi
180.0 bar
|
| Valves: | 1
|
| Pump flow: | 10.6 gpm
40.1 lpm
|
| SCV flow: | 4.2 gpm
15.9 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | top link draft sensing
|
| Rear lift: | 7868 lbs
3568 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| | 540/1000*Optional
|
| Engine RPM: | 540@1994
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 55
|
| Battery volts: | 12
|
