Montana R4344
|
|
| Production | |
| Distributor | Montana |
| Manufacturer | LS |
| Compact Utility tractor | |
| Variants | |
| CT41 | similar McCormick Intl model |
| Montana R4344 Engine | |
| Mitsubishi 2.3L 4-cyl diesel | |
| Fuel tank | 10 gal 37.9 L |
 Engine details ... | |
| Montana R4344 Transmissions | |
| 16-speed sync shuttle | |
| hydrostatic | |
 Transmission details ... |
| Montana R4344 Power | |
| Engine (gross) | 41 hp 30.6 kW |
| Gear PTO (claimed) | 36 hp 26.8 kW |
| Hydro PTO (claimed) | 34 hp 25.4 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. |
| Photos | |
| No photos of the Montana R4344 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2560 psi 176.5 bar |
| Valves | 2 |
| Pump flow | 8.2 gpm 31.0 lpm |
| Steering flow | 4.121 gpm 15.6 lpm |
| Steering press. | 2062 psi 142.2 bar |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 2755 lbs 1249 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | optional |
| Dimensions & Tires | |
| Wheelbase | 69 inches 175 cm |
| Weight | 3582 lbs 1624 kg |
| Front tire | 8-16 |
| Rear tire | 12.4-24 |
 Full dimensions and tires ... | |
| Montana R4344 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| R4344 Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 50 |
| Battery volts | 12 |
| References | |
 | |
| CBL Compact Backhoe Loader published in 2005, by Montana |
