Montana 4920


Montana 4920 tractor photo
2005 - 2009
Compact Utility tractor
LG built
Production
Distributor:Montana
Manufacturer:LG
Type:Compact Utility tractor
Variants
4920:2WD ROPS
4920C:2WD Cab
4940:4WD ROPS
4940C:4WD Cab
Montana 4920 Power
Engine:49 hp
36.5 kW
Montana 4920 Engine
Mitsubishi 2.5L 4-cyl diesel
Cab Fuel tank:13.5 gal
51.1 L
ROPS Fuel tank:15.9 gal
60.2 L
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:power
Brakes:wet disc
Cab:Two-post ROPS. Big Sky cab optional.
Transmission:16-speed sync shuttle
Transmission details ...
Photos
No photos of the Montana 4920 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Valves:2
Pump flow:8.43 gpm
31.9 lpm
Tractor hitch
Rear Type:I
Control:position and draft control
Rear lift (at ends):3197 lbs
1450 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
Weight:4321 to 5202.8 pounds
Front tire:9.5-20
Rear tire:13.6-28
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:45
Battery volts:12
