TYM T580
| | 2004 - 2006 |
| Utility tractor |
|
| Production |
| Manufacturer: | TYM
|
| Type: | Utility tractor
|
| TYM T580 Power |
| Engine (gross): | 58 hp
43.3 kW
|
| Engine (net): | 55 hp
41.0 kW
|
| PTO (claimed): | 51 hp
38.0 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post foldable ROPS. Cab optional.
|
| Transmission: | 16-speed sync shuttle
|
 Transmission details ... |
| Photos |
| No photos of the TYM T580 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel: | 17 gal
64.3 L
|
| Hydraulic system: | 11 gal
41.6 L
|
| Hydraulics |
| Type: | dual gear pump
|
| Capacity: | 11 gal
41.6 L
|
| Rear valves: | 3
|
| Front valves: | 1
|
| Pump flow: | 10.12 gpm
38.3 lpm
|
| Total flow: | 15.06 gpm
57.0 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and draft control
|
| Rear lift (at ends): | 4,241 lbs
1923 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/750
|
| | 540/1000 (optional)
|
| T580 Serial Numbers |
| Location: | Serial number on the left front side of the tractor frame, above the front axle.
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 50
|
| Battery volts: | 12
|
| Page information |
| Last update: | May 26, 2017
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
